21
Camera Control Behaviors
1. Power button — when the camera is off, a brief press turns it on; when the camera is on, a brief
press turns it off
2. Lytro button — a half-press displays depth feedback for the object at the center of the frame; a
full-press displays a live depth histogram and depth overlay
3. Shutter button — a half-press engages auto exposure lock (AEL); a full-press releases the shutter
4. Front dial — sets the ISO (in ISO Priority Mode); sets Shutter Speed (in Shutter Speed Priority
Mode and Manual Mode)
5. Zoom ring — adjusts the focal length of the lens
6. Focus ring — adjusts the focus of the lens
7. Touchscreen — Provides view of scene through the lens, plus touch screen menus and informa-
tion
8. Rear dial — sets the EV compensation in Program, ISO Priority, and Shutter Speed Priority
Modes; sets the ISO in Manual Mode
9. AF button — activates autofocus when pressed
10. AEL button — locks the exposure at the current setting while held down
11. Fn — toggles between Capture Mode and Playback Mode
12. Hyperfocal button — sets the focus of the lens to the light eld hyperfocal position (moves the
far end of the refocusable range to innity)
