Lytro Illum User Manual

80
Adjusting Optical Offset
To adjust the optical offset, add the Optical Offset icon to the Menu Bar (see Rearrange Menu), then tap it. The Menu Bar will be
hidden, and a depth scale will be displayed.
Bands in shades of blue represent the near refocusable range, and bands in shades of orange represent the far refocusable range.
The current optical offset position is indicated by a white band (the default position is -4). Rotate the front dial to relocate the opti-
cal offset closer or further away in the refocusable range.
Rotate the front dial to adjust the optical offset.
To close the depth scale, unhide the Menu Bar by swiping left from the right edge of the screen. The optical offset will remain at
the new setting until it is changed using these same steps.
Optical Offset

Lytro Illum Specifications

General

Megapixel	- MP
Camera type	Bridge camera
Sensor type	CMOS
Image stabilizer	No
Image sensor size	1/1.2 \
Supported aspect ratios	3:2
Maximum image resolution	2450 x 1634 pixels
Image sensor size (W x H)	10.82 x 7.52 mm
Still image resolution(s)	2450 x 1634
Digital zoom	- x
Optical zoom	8 x
Focal length range	9.5 - 77.8 mm
Minimum aperture number	-
Maximum focal length (35mm film equiv)	250 mm
Minimum focal length (35mm film equiv)	30 mm
Focus adjustment	Auto
Light metering	Evaluative (Multi-pattern)
ISO sensitivity	80, 3200
Light exposure modes	Manual, Shutter priority AE
ISO sensitivity (max)	3200
ISO sensitivity (min)	80
Light exposure control	Program AE
Auto Exposure (AE) lock	Yes
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	32 s
HD type	Not supported
Maximum video resolution	- pixels
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	4 \
Display resolution	480 x 800 pixels
USB version	3.2 Gen 1 (3.1 Gen 1)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Self-timer delay	2, 10 s
Camera file system	RAW
Mac operating systems supported	Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Power source type	Battery
Battery voltage	3.7 V
Battery capacity	3760 mAh
Material	Aluminium, Magnesium
Product color	Black
Sustainability certificates	RoHS
Cables included	Micro-USB
Bundled software	Lytro Desktop
F-number (relative aperture)	2
Storage temperature (T-T)	2450 x 1634 °C

Weight and Dimensions

Depth	166 mm
Width	145 mm
Height	86 mm
Weight	940 g
Weight (including battery)	1029 g
