Lytro Illum User Manual

27
Capture Mode, Information Bar
1. ISO indicator — displays the current ISO; tap to set ISO in ISO Priority Mode and Manual Mode
2. Shutter speed indicator — displays the current shutter speed; tap to set speed in Shutter Priority Mode and Manual Mode
3. EV compensation indicator — displays the compensation currently selected; tap to set compensation (not available in Manual
Mode)
4. Exposure mode indicator — P for Program, I for ISO Priority, S for Shutter Speed Priority, M for Manual; replaced by a lock sym-
bol when AE is locked
5. White balance indicator — displays the current white balance setting
6. Focal length indicator — displays the current focal length (35mm equivalent)
7. Shot buffer indicator — displays the number of shots remaining in the internal buffer used for burst capture; when the indicator
reaches zero, the maximum continuous frame rate is limited by the write speed of the SD card
8. Shots remaining indicator — displays how many additional Living Pictures the SD card can hold; when no SD card is inserted, the
no SD card indicator will appear here
9. Battery remaining indicator — displays the battery’s remaining charge
10. Wi-Fi (iOS Connect) indicator — visible only when the camera is enabled as an access point in Settings, iOS Connect
11. Full screen mode -- Hides all extraneous data for simple composition.

Lytro Illum Specifications

General

Megapixel	- MP
Camera type	Bridge camera
Sensor type	CMOS
Image stabilizer	No
Image sensor size	1/1.2 \
Supported aspect ratios	3:2
Maximum image resolution	2450 x 1634 pixels
Image sensor size (W x H)	10.82 x 7.52 mm
Still image resolution(s)	2450 x 1634
Digital zoom	- x
Optical zoom	8 x
Focal length range	9.5 - 77.8 mm
Minimum aperture number	-
Maximum focal length (35mm film equiv)	250 mm
Minimum focal length (35mm film equiv)	30 mm
Focus adjustment	Auto
Light metering	Evaluative (Multi-pattern)
ISO sensitivity	80, 3200
Light exposure modes	Manual, Shutter priority AE
ISO sensitivity (max)	3200
ISO sensitivity (min)	80
Light exposure control	Program AE
Auto Exposure (AE) lock	Yes
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	32 s
HD type	Not supported
Maximum video resolution	- pixels
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	4 \
Display resolution	480 x 800 pixels
USB version	3.2 Gen 1 (3.1 Gen 1)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Self-timer delay	2, 10 s
Camera file system	RAW
Mac operating systems supported	Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Power source type	Battery
Battery voltage	3.7 V
Battery capacity	3760 mAh
Material	Aluminium, Magnesium
Product color	Black
Sustainability certificates	RoHS
Cables included	Micro-USB
Bundled software	Lytro Desktop
F-number (relative aperture)	2
Storage temperature (T-T)	2450 x 1634 °C

Weight and Dimensions

Depth	166 mm
Width	145 mm
Height	86 mm
Weight	940 g
Weight (including battery)	1029 g
