MacDon FlexDraper FD135 - Page 297

214683 273 Revision A
1016049
A
Figure 3.478: New Holland Combine Display
5. Select DIAGNOSTICS (A) on the main screen. The
DIAGNOSTICS screen displays.
1016050
A
Figure 3.479: New Holland Combine Display
6. Select SETTINGS (A). The SETTINGS screen displays.
1016053
A
B
Figure 3.480: New Holland Combine Display
7. Select HEADER HEIGHT/TILT (A) from the GROUP
drop-down menu.
8. Select HEADER HEIGHT SENS. L (B) from the
PARAMETER drop-down menu.
OPERATION
