MacDon FlexDraper FD135 - Page 421

214683 397 Revision A
Figure 5.11: Every 250 Hours
10194281019428
B
A
A
A
B
A - Frame/Wheel Pivot (Front and Rear) – Both Sides B - Front Wheel Pivot (One Place)
Every 500 Hours
Use high temperature extreme pressure (EP2) performance grease with 1% max molybdenum disulphide
(NLGI Grade 2) lithium base unless otherwise specified.
MAINTENANCE AND SERVICING
