Table 3.4 Recommended FD1 Series / FM100 Combine Header Settings for Peas
Stubble Height On ground
Stabilizer
Wheels
13
Storage
Skid Shoe
Position
Up or middle
Crop
Condition
Divider Rods
Draper Speed
Setting
14
Header
Angle
15 16
Reel Cam
Reel
Speed %
17
Reel Position
Upper Cross
Auger
Light
On
7
B – C
25–10 6 or 7 Recommended
Normal
On
7
B – C
2 10 6 or 7 Recommended
Heavy
On
7
B – C
2 10 4 or 5 Recommended
Lodged
On
7D
25–10
4 or 5 Recommended
13. Stabilizer wheels are used to limit the side-to-side movement when cutting off the ground in rolling terrain and to minimize bouncing.
14. Setting on FM100 draper control.
15. Set header angle as shallow as possible (setting A) with center-link and skid shoes while maintaining cutting height.
16. Cutting height is controlled with a combination of skid shoes and header angle.
17. Percentage above ground speed.
