MacDon R113 - Page 21

214633 9 Revision C
Ref
Part
Number Description Qty
1
30753 FASTENER - CABLE TIE BLACK
8
2 184301 CLAMP
2
3 135235 CLAMP - DOUBLE HOSE INSULATED
3
4
21763 FASTENER - CABLE TIE BLACK
6
5
281101 PIN - CLEVIS
2
6 18609
PIN - COTTER 1/4 DIA X 2 ZP
2
7
120333 PIN - CLEVIS, 18.95 MM, 127 MM
1
8 18648
PIN - COTTER 3/16 DIA X 1.25 ZP
1
9 136383 COLLAR - HOSE IDENTIFICATION BLUE 1
2
10 135563 FITTING - COUPLING HYD 1
11
30340 CAP - PLASTIC 1
12 136149
FITTING - ELBOW 90°HYD CW O-RING
1
13 136147 FITTING - CONNECTOR HYD 1
14
136453
3
FITTING - TEE HYD 1
15
19958 PIN - CLEVIS 1
16
18608
PIN - COTTER 3/16 DIA X 1.5 ZP
1
17 134741 CAP-PLUG, DEUTSCH, DT, 2 POS.
1
18 134742 CAP-PLUG, DEUTSCH, DT, 3POS.
1
A
136431 NUT - HEX FLG CTR LOC M12X1.75-10 4
B
136178 BOLT - RHSN M10X1.5X20-8.8-A3L 4
C 50101
4
NUT - HEX FLG STVR LOC M10X1.5-10-A3L
6
D
135799 NUT - HEX FLG CTR LOC M10X1.5-10
2
E
184657
5
BOLT - RHSSN M10X1.5X20-8.8-AA1J
2
F
184711 WASHER - FLAT REG M10-200HV-AA1J
2
G 136399 BOLT - HEX FLG HD TFL M12X1.75X25-8.8-A3L 3
H
184667 BOLT - RHSN M12X1.75X30-8.8-AA1J 4
K
136313 SCR-PAN HD M4X0.7X16-4.8-AA1J 2
J
030855 NUT-HEX M4X0.7-8-AA1J 2
PARTS LIST
3. Only used on a pull-type from model year 2017 or prior.
4. Only four are used.
5. Not used.
