Programming menu No.2
 When the doors are opened and ignition is on, keep the buttons I and IV pressed for 2 sec.
No.
Function
Options
Button I
Button II
Button III
Button IV
2-01
Trunk output time
0.5 sec.
2 sec.
3 sec.
4 sec.
2-02
Door lock impulse
0.8 sec.
4 sec.
2 x 0.8 sec.
15 sec.
2-03
Door unlock impulse
0.8 sec.
4 sec.
2 x 0.8 sec.
-
2-04
Door lock/unlock
impulse during remote
start
Off
Lock impulse
after remote start
Unlock impulse
before remote start
&lock impulse after
remote start
-
2-05
Door lock impulse after
remotely started engine
will go Off
Off
On
-
-
2-06
Parking lights
Normal mode
Continuous mode
Pulse mode
-
2-07
Start output (TACH)
ST-1
ST-2
ST-3
-
2-08
AUX 1
0.5 sec.
5 sec.
40 sec.
Latch
2-09
AUX 2
0.5 sec.
5 sec.
40 sec.
Latch
2-10
AUX 2 BYPASS function
On
Off
-
-
2-11
Shock sensor on/off
during AUX output
On
Off
-
-
2-12
Cold start
Off
-5 ºC
-15 ºC
-25 ºC
2-13
Arm/disarm by OEM
remote control
Enabled
Disabled
-
-
2-14
Lights by CAN
Enabled
Disabled
Only during alert
-
2-15
Klaxon by CAN
Enabled
Disabled
-
-
2-16
Brakes by CAN
Hand and
Foot brake
only Hand brake
only Foot brake
brakes will
be note read
by CAN
Function explanation:
2-01 Impulse time set-up for trunk output.
2-02 Impulse time set-up for door lock.
2-03 Impulse time set-up for door unlock.
2-04 You can set the central door lock outputs reactions when remote starting activated. Advisable if you
need the door open at remote starting.
2-05 Option to lock the vehicle after remote starting.
2-06 Using this function, you can set the lights control by the alarm mode.
- normal – mainly for direct control of hazard lights by (-) or (+).
- continuous, pulse – designed to sequential control of directional lights (see page 47).
2-07 Duration of engine starting sequence. Possible choose from 1, 1.3 or 1.7 seconds.
2-08 Duration of negative impulse for AUX output No.1 (grounded when activated)
2-09 Duration of negative impulse for AUX output No.2 (grounded when activated)
2-10 It is possible to set the AUX output No 2 as a bypass output. In this case the output will be activated
when remotely started, and can be used e.g. for the transponder bypass module. When remote starting is
finished, the output will be deactivated.
2-11 It allows you to deactivate a shock sensor by using additional outputs in case connected device is
causing sensor reaction.
2-12 It allows you to set the temperature at which, if the regular starting function on, remote starting will be
carried out. But in case the temperature is higher than the pre-set one, starting will not be carried out!
2-13 When function is disabled then is not possible to arm or disarm alarm by original remote control only
by system remote control. When function is enabled alarm will be armed or disarmed by original and system
remote control. Alarm must be connected to CAN bus via CAN BUS Magicar module.
2-14 Options enabled or disabled transmitting information by unit for light control via CAN.
2-15 Options enabled or disabled transmitting information by unit for acoustics signalization via CAN.
2-16 Option allows setting what kind of information’s about the brakes will be read and processed by the
module CAN BUS Magicar. Status of analogue inputs is always in process.
