Quattro DC Troubleshooting
108
Name Description
Possible Causes & Corrective Action
Line HI Volts
Line voltage is greater than
max drive rating. Monitored via
the DC Bus.
Line Voltage is too High
Verify DC Bus is reading voltage correctly
Verify Line voltage is set correctly
LS A to D
The Analog to Digital
conversion on the line side
control board is not working
properly.
Line Side Analog to Digital Conversion
incorrect
Replace Line Side Main and Power Interface
PCBs
LS AC CNTCR
The main AC power contactor
is not following the commanded
state within 1 second.
AC Power Contactor Problem
Check for faulty UTM contactor coil or
interlocking aux contact blocks on PCM or
UTM
Check A8 TB3-9 has 24Vdc, it then goes
through the aux on the UTM to A8 TB3-18,
with the line power off close UTM, the 24V on
A8 TB3-18 should go to zero. If this checks it
may be a bad product interface PCB on the
line side
CAUTION: Do not manually engage the UTM
contactor with power applied.
LS BRDG GND
The hardware has detected a
ground fault on the line side
power bridge.
IGBT Breakdown
Inspect and measure for physical voltage
breakdown damage on IGBTs and DC bus
LS Charge
The DC bus voltage has not
stabilized above the voltage
fault level within 2 seconds or
the charge contactor has not
closed after charging
OR
The DC bus voltage is below
the UV Fault level as defined
by the INPUT L-L VOLTS (A5)
and UV FAULT LEVEL (A4)
parameters
Please note, if LS Charge
occurs 3 consecutive times, the
drive will require a power cycle
to reset the fault
Low Input Voltage
Check INPUT L-L VOLTS (A5) and UV FAULT
LEVEL (A4) parameters
Verify proper input voltage and increase, if
necessary, the input AC voltage within the
proper range
Check for a missing input phase
Check power line disturbances due to starting
of other equipment
Incorrect Setting
Verify the PCM pulls in
Observe DC BUS VOLTS (D3) and verify it
increases until the fault occurs
Observe DC BUS VOLTS (D3) decreased
after the fault as occurred
DC Bus Problems
Observe DC BUS VOLTS (D3)
Manually push in PCM, do not hold for longer
than 1s!! Does the bus voltage rise, if so does
it decay slowly or rapidly drop to zero.
If it stays at zero or drops quickly, it indicates
the bus is shorted.
Hardware Failure
Possible Damaged Product Interface Board
Possible Damaged Pre-Charge Resistor and /
or Pre-Charge Contactor
Possible field module failure / shorted motor
field
