Quattro DC Quick Parameter Reference
13
Sub
menu
Parameter Units Range Default
Site
Setting
C2
Logic Inputs C2 Submenu – See Logic Inputs C2 submenu on page 78.
C2 N.C. INPUTS
none Hex Number
0X01
C2
LOGIC INPUT 1 TB1(1)
 contact cfirm
 ctr pwr sense
 drive enable
 extrn fault 1
 extrn fault 2
 extrn fault 3
 extrn /flt 4
 fault reset
 field enable
 low gain sel
 mech brk hold
 mech brk pick
 no function
 ospd test src
 ntsd input1
 ntsd input 2
 pre-trq latch
 run
 run 2
 run down
 run up
 s-curve sel 0
 s-curve sel 1
 ser2 insp ena
 step ref b0
 step ref b1
 step ref b2
 step ref b3
 trq ramp down
 up/dwn
CONTACT CFIRM
fixed
LOGIC INPUT 2 TB1(2) CTR PWR SENSE
fixed
LOGIC INPUT 3 TB1(3)
LOGIC INPUT 4 TB1(4)
LOGIC INPUT 5 TB1(5)
LOGIC INPUT 6 TB1(6)
LOGIC INPUT 7 TB1(7)
LOGIC INPUT 8 TB1(8)
LOGIC INPUT 9 TB1(9)
C3
Logic Outputs C3 Submenu – See Logic Outputs C3 submenu on page 70
LOGIC OUTPUT 1
TB1(25
 alarm
 alarm+flt
 auto brake
 b. ena status
 brake hold
 brake pick
 brk hold flt
 brk pick flt
 car going dwn
 car going up
 charge fault
 close contact
 contactor flt
 curr reg flt
 drv overload
 encoder flt
 fault
 flux confirm
 ground fault
 in low gain
 motor trq lim
 mtr overload
 no faults
 no function
 not alarm
 ntsd Active
 over curr flt
 overspeed flt
 overtemp flt
 overvolt flt
 ovrtemp alarm
 phase fault
 ramp down ena
 ready 2 start
 ready to run
 regen trq lim
 run commanded
 run confirm
 speed dev
 speed dev low
 speed ref rls
 speed reg rls
 undervolt flt
 up to speed
 uv alarm
 zero speed
CLOSE
CONTACT
LOGIC OUTPUT 2
TB1(26)
RUN
COMMANDED
LOGIC OUTPUT 3
TB1(27)
MTR OVERLOAD
LOGIC OUTPUT 4
TB1(28)
ENCODER FLT
LOGIC OUTPUT 5
TB1(29)
FAULT
LOGIC OUTPUT 6
TB1(30)
SPEED REG
RLS
LOGIC OUTPUT 7
TB1(31)
SPEED REG
RLS
SSR1 TB1(21/22) NO FUNCTION
SSR2 TB1(23/24) NO FUNCTION
RELAY COIL 1
TB2(1/3/5)
NO FUNCTION
RELAY COIL 2
TB2(8/10/12)
NO FUNCTION
C4
Analog Outputs C4 Submenu – See analog Outputs C4 submenu on page 72
C4 ANA OUT 1 TB1-12
 analog addr2
 analog addr3
 arb state
 arm current
 arm voltage
 pretorque ref
 motor mode
 spd rg tq cmd
 speed command
 speed error
SPEED REF
