Quattro DC Quick Parameter Reference
12
Sub
menu
Parameter Units Range Default
Site
Setting
C1 User switches C1 Submenu continued …
C1 FAULT RESET SRC none
 external tb
 serial
 automatic
EXTERNAL TB
C1 BRAKE PICK SRC none
 internal
 serial
INTERNAL
C1 BRAKE PICK CNFM
none
 none
 external tb
 internal time
 on speed cmd
NONE
C1 BRAKE HOLD SRC none
 internal
 serial
INTERNAL
C1 RAMPED STOP SEL none
 none
 ramp on stop
NONE
C1 RAMP DOWN EN SRC none
 external tb
 run logic
 serial
EXTERNAL TB
C1 BRK PICK FLT ENA
none
 disable
 enable
DISABLE
C1 BRK HOLD FLT ENA none
 disable
 enable
DISABLE
C1 EXT TORQ CMD SRC
none
 none
 serial
 analog input
NONE
C1 DIR CONFIRM
none
 disabled
 enabled
DISABLED
C1 S-CURVE ABORT
none
 disabled
 enabled
DISABLED
C1 PRIORITY MESSAGE none
 disable
 enable
ENABLE
C1 STOPPING MODE
none
 immediate
 ramp to stop
IMMEDIATE
C1 AUTO STOP
none
 enable
 disable
DISABLE
C1 DSPR ENABLE
none
 disable
 enable
DISABLE
C1 ARB SELECT
none
 disable
 enable
DISABLE
C1 SERIAL MODE none
 none
 mode 1
 mode 2
 mode 2 Test
NONE
C1 SER2 FLT MODE none
 immediate
 run remove
 rescue
IMMEDIATE
C1 NTSD Mode none
 external
 1 threshold
 2 thresholds
 3 thresholds
EXTERNAL
C1
C1 DSPR ENABLE none
 disable
 enable
DISABLE
