Quattro DC Quick Parameter Reference
11
Sub
menu
Parameter Units Range Default
Site
Setting
A6
Motor A6 Submenu – See Motor Parameters A6 submenu on page 59.
A6 MOTOR ID None - -
A6 RATED MOTOR CURR amps 1.0 – 400.0 0.0
A6 ARMATURE VOLTAGE volts 55 – 600 0
A6 FULL FLD CURRENT amps 1.0 – 40.0 0.0
A6 WEAK FLD CURRENT amps 1.0 – 40.0 0.0
A6 STANDBY FIELD amps 0.0 – 40.0 0.0
A6 FLUX CONFIRM LEV % 25.0 – 99.0 85.0
A6 ARMATURE IR DROP % 0.0 – 25.0 0.0
A6 TACH VOLT SENSE % 0.1 – 60.0 25.0
A6 TACH SPEED SENSE % 0.1 – 40.0 5.0
A6 OVLD START LEVEL % 100 – 150 110
A6 OVLD TIME OUT sec 5.0 – 120.0 60.0
A6 SAVE MEAS ARM L mH 0.00 – 327.67 0.00
A6 SAVE IR DROP % 0.0 – 3276.7 0.0
A6 SAVE MEAS ARM R ohm 0.0000 – 3.2767 0.0000
A6 SAVE FIELD RES ohm 0.0 – 3276.7 0.00
A6 SAVE FIELD TC sec 0.000 – 32.767 0.000
C1 User Switches C1 Submenu – See User Switches C1 submenu on page 64.
C1 SPD COMMAND SRC
none
 serial
 multi-step
 ser mult step
 analog input
MULTI-STEP
C1 RUN COMMAND SRC
none
 external tb
 serial
 serial+extrn
EXTERNAL TB
C1 FIELD ENA SOURCE
none
 external tb
 serial
 enable on run
 2-bit serial
ENABLE ON RUN
C1 HI/LO GAIN SRC
none
 internal
 external tb
 serial
INTERNAL
C1 SPEED REG TYPE
none
 elev spd reg
 pi speed reg
 external reg
 cemf reg
ELEV SPD REG
C1 MOTOR ROTATION none
 forward
 reverse
FORWARD
C1 ENCODER CONNECT
none
 forward
 reverse
FORWARD
C1 SPD REF RELEASE
none
 reg release
 brake picked
REG RELEASE
C1 CONT CONFIRM SRC none external tb EXTERNAL TB fixed
C1 TACH FILTER
none
 Off
 On
OFF
C1 PreTorque SOURCE
none
 none
 analog input
 serial
NONE
C1 PreTorque LATCH
none
 latched
 not latched
NOT LATCHED
C1 PTorq LATCH CLCK
none
 external tb
 serial
EXTERNAL TB
C1 OVERSPD TEST SRC
none
 external tb
 serial
EXTERNAL TB
