Appendix – Spare Parts List
169
Description
Pictorial
Reference
Drive
Rating
Reference
Designator
Magnetek kit
Number
Quantity
Per
Drive
Shaft Ground brush
This contains only the brush,
it will require a mounting
bracket to attach to the
motor. The brush comes in
two different sizes, select the
quantity required and type
based on the description
provided.
Use 1.0 for shaft
diameters up to
3IN(76mm), use 2.0
for 5-8IN(127-
203mm), use 3.0 for
9-10IN(228-254mm)
ALL - 05P00066-0681
Use 1.0 for 5-
8IN(127-203mm),
use 2.0 for 9-
10IN(228-254mm)
ALL - 05P00066-0682
Door Fan Kit
Includes adaptor plate, fans,
cables to upgrade drive that
weren’t manufactured with
fans in the door
24IN Enclosure ALL -
Q2B-24IN-
DOORFAN
-
32IN Enclosure All -
Q2B-32IN-
DOORFAN
-
DC output filter
Optional DC Output Filters are designed to
offer an additional level of protection to existing
DC machines in a modernization project. The
DC filters are designed to provide a reduction
in the change in voltage with respect to time
(dv/dt) of 500V/micro second or less as
recommended by the NEMA MG-1 Motor &
Generator design guide.
DC Output filters are available in the following 5
configurations
1. Armature and field filter mounted on a sub-
panel for mounting internal to the Quattro DC
Cabinet **
2. Armature and field filter mounted in a
standalone NEMA 1 enclosure for locating
external to the Quattro DC Cabinet **
3. Armature only filter mounted on a sub-panel
for mounting internal to the Quattro DC
Cabinet **
4. Armature only filter mounted in a standalone
NEMA 1 enclosure for locating external to the
Quattro DC Cabinet
5. The drive can be built in the factory with this
filter integrated into the product. Refer to the
drive model numbers section in the front of
this manual.
** Can be located in the location under the auto-
transformer if it isn’t installed. Otherwise, refer to the
standalone NEMA 1 options, these options are for
field retrofit.
QDC-0125-01
- 125A Panel only, field and armature
QDC-1125-01
- 125A NEMA Enclosed, field and armature
QDC-2125-01
- 125A Panel only, armature
QDC-3125-01
- 125A NEMA Enclosed, armature
QDC-0150-01
- 150A Panel only, field and armature
QDC-1150-01
- 150A NEMA Enclosed, field and armature
QDC-2150-01
- 150A Panel only, armature
