Quattro DC Motor A6 Submenu
60
Parameter Description Units Default Range
Hidden
Item
Run
lock
out
TACH VOLT
SENSE
(Tachometer Voltage Sense)
Sets the minimum armature voltage where
the Encoder Loss and Reverse Tach
functions will become operative. This
parameter prevents nuisance encoder faults
during low speeds and high torque
conditions by adjusting the encoder loss
sensitivity to motor IR drop. Works in
conjunction with TACH SPEED SENSE. An
ENCODER FLT will be declared if the
following two equalities are satisfied:


























(D2) VOLTAGE
ARMATURE
(A6) VOLTAGE
ARMATURE
(A6) SENSE
VOLT TACH
and






























(D1)
FEEDBACK
SPEED
(A1) SPEED
CAR
CONTRACT
(A6) SENSE
SPEED TACH
% 25.0 0.1 – 60.0
N N
TACH SPEED
SENSE
(Tachometer Speed Sense)
Sets the level of measured speed feedback
below which an Encoder Loss Fault is
declared – once motor armature voltage
conditions are satisfied. Works in conjunction
with TACH VOLT SENSE. An ENCODER
FLT will be declared if the following two
equalities are satisfied:


























(D2) VOLTAGE
ARMATURE
(A6) VOLTAGE
ARMATURE
(A6) SENSE
VOLT TACH
and






























(D1)
FEEDBACK
SPEED
(A1) SPEED
CAR
CONTRACT
(A6) SENSE
SPEED TACH
% 5.0 0.1 – 40.0
N N
OVLD START
LEVEL
(Motor Overload Start Level)
This parameter defines maximum current at
which motor can run continuously without
triggering the motor overload. One of the
two parameters that define the motor
overload curve. Set as a percent of Rated
Motor Current. For more information on the
motor overload curve, see OVLD TIME OUT
and OVLD START LEVEL on page 62.
% 110 100 – 150
N Y
OVLD TIME OUT
(Motor Overload Time Out)
This parameter defines the amount of time
before a motor overload alarm occurs when
the motor is running at the current level
defined below:

























current
motor
rated
LEVEL
START
OVLD
%40
:
This is the other parameter used to define
the overload curve. For more information on
the motor overload curve, see OVLD TIME
OUT and OVLD START LEVEL on page 62.
sec 60.0 5.0 – 120.0
N Y
