Quattro DC Motor A6 Submenu
61
Parameter Description Units Default Range
Hidden
Item
Run
lock
out
SAVE MEAS ARM
L
(Saved Measured Armature Circuit
Inductance)
Affects tuning of the armature current
regulator. This parameter will automatically
fill with measured value AUTO MEAS ARM
R (D2) after Auto-Tune. This parameter is
used only if GAIN SELECTION (A4) is set to
USE SAVED PAR.
Note: This parameter cannot be adjusted via
the handheld operator.
mH 0.00
0.00 –
327.67
N Y
SAVE IR DROP
(Saved Armature IR Drop)
Adjusts motor armature current regulator for
expected current multiplied by resistance
voltage drop of motor armature circuit at
rated current. Includes motor armature,
inter-poles and wiring resistance. This
parameter will automatically fill with the
measured value AUTO MEAS IR DROP (D2)
after Auto-Tune. This parameter also affects
the sensitivity of the fault, Encoder Fault.
This parameter is used only if GAIN
SELECTION (A4) is set to USE SAVED
PAR.
Note: This parameter cannot be adjusted via
the handheld operator.
% 0.0
0.0 –
3276.7
N Y
SAVE MEAS ARM
R
(Saved Measured Armature Circuit
Resistance)
Affects tuning of the armature current
regulator. This parameter will automatically
fill with measured value AUTO MEAS ARM L
(D2) after Auto-Tune. This parameter is
used only if GAIN SELECTION (A4) is set to
USE SAVED PAR.
Note: This parameter cannot be adjusted via
the handheld operator.
ohm 0.0000
0.0000 –
3.2767
N Y
SAVE FIELD RES
(Saved Measured Field Resistance)
Affects tuning of the field current regulator.
This parameter automatically fills in with
AUTO MEAS FIELD RES (D2) after auto-
tune. This parameter is used only if GAIN
SELECTION (A4) is set to USE SAVED
PAR.
Note: This parameter cannot be adjusted via
the handheld operator.
ohm 0.0
0.0 –
3276.7
Y Y
SAVE FIELD TC
(Saved Measured Field Time Constant)
Affects tuning of the field current regulator.
This parameter automatically fills in with
AUTO MEAS FIELD TC (D2) after auto-tune.
This parameter is used only if GAIN
SELECTION (A4) is set to USE SAVED
PAR.
Note: This parameter cannot be adjusted via
the handheld operator.
sec 0.000
0.000 –
32.767
N Y
