Quattro DC Quick Parameter Reference
7
Sub
menu
Parameter Units Range Default
Site
Setting
A1 DSPR TIME min 0 – 546 10
A1 FULL FIELD FLT TIME min 0 – 99 1
A1 SER2 INSP SPD
ft/s2 0 – 100 30
m/s2
0
–
0.500
0.150
A1 SER2 RS CRP SPD
ft/s2 0 – 300 10
m/s2 0 – 1.540 0.050
A1 SER2 RES CRP TIME Sec 0 – 200.0 180
A1 SER2 FLT TOL Sec 0 – 2.00 0.5
A2 S-Curves A2 Submenu – See S-Curves A2 submenu on page 51.
A2 ACCEL RATE 0
ft/s
2
0.00 – 7.99 7.99
m/s
2
0.000 – 3.999 2.000
A2 DECEL RATE 0
ft/s
2
0.00 – 7.99 7.99
m/s
2
0.000 – 3.999 2.000
A2 ACCEL JERK IN 0
ft/s
3
0.0 – 29.9 0.0
m/s
3
0.00 – 9.99 0.00
A2 ACCEL JERK OUT 0
ft/s
3
0.0 – 29.9 0.0
m/s
3
0.00 – 9.99 0.00
A2 DECEL JERK IN 0
ft/s
3
0.0 – 29.9 0.0
m/s
3
0.00 – 9.99 0.00
A2 DECEL JERK OUT 0
ft/s
3
0.0 – 29.9 0.0
m/s
3
0.00 – 9.99 0.00
A2 ACCEL RATE 1
ft/s
2
0.00 – 7.99 7.00
m/s
2
0.000 – 3.999 0.090
A2 DECEL RATE 1
ft/s
2
0.00 – 7.99 3.00
m/s
2
0.000 – 3.999 0.090
A2 ACCEL JERK IN 1
ft/s
3
0.0 – 29.9 8.0
m/s
3
0.00 – 9.99 2.40
A2 ACCEL JERK OUT 1
ft/s
3
0.0 – 29.9 8.0
m/s
3
0.00 – 9.99 2.40
A2 DECEL JERK IN 1
ft/s
3
0.0 – 29.9 8.0
m/s
3
0.00 – 9.99 2.40
A2 DECEL JERK OUT 1
ft/s
3
0.0 – 29.9 8.0
m/s
3
0.00 – 9.99 2.40
A2 ACCEL RATE 2
ft/s
2
0.00 – 7.99 3.00
m/s
2
0.000 – 3.999 0.090
A2 DECEL RATE 2
ft/s
2
0.00 – 7.99 3.00
m/s
2
0.000 – 3.999 0.090
A2 ACCEL JERK IN 2
ft/s
3
0.0 – 29.9 8.0
m/s
3
0.00 – 9.99 2.40
A2 ACCEL JERK OUT 2
ft/s
3
0.0 – 29.9 8.0
m/s
3
0.00 – 9.99 2.40
A2 DECEL JERK IN 2
ft/s
3
0.0 – 29.9 8.0
m/s
3
0.00 – 9.99 2.40
A2 DECEL JERK OUT 2
ft/s
3
0.0 – 29.9 8.0
m/s
3
0.00 – 9.99 2.40
A2 ACCEL RATE 3
ft/s
2
0.00 – 7.99 3.00
m/s
2
0.000 – 3.999 0.090
A2 DECEL RATE 3
ft/s
2
0.00 – 7.99 3.00
m/s
2
0.000 – 3.999 0.090
A2 ACCEL JERK IN 3
ft/s
3
0.0 – 29.9 8.0
m/s
3
0.00 – 9.99 2.40
A2 ACCEL JERK OUT 3
ft/s
3
0.0 – 29.9 8.0
m/s
3
0.00 – 9.99 2.40
A2 DECEL JERK IN 3
ft/s
3
0.0 – 29.9 8.0
m/s
3
0.00 – 9.99 2.40
