13
Control unit MGCplus
Operation modes
3 Operation modes
3.1 Description
The pedestrian gate is equipped with various operating modes.
You can force the various operating modes as follows:
› Set the input with the corresponding function. For example, if you select
the "Contr. D1/Closed D2" input, this operating mode is activated. ä Page
23, chapter 4.1.
› Control the behaviour of the pedestrian gate using the input functions
"Control direction 1", "Control direction 2" and "Control open mode". The
"Control variant " parameter must be parameterized to match the applica-
tion case. ä Page 17, chapter 3.4 and ä Page 41, "Control variant".
Input functions that force a certain operating mode have a higher priority than
the input functions "Control direction 1" and "Control direction 2".
The input function | Emergency open or emergency open have the highest pri-
ority.
Operating mode Description
No access The pedestrian gate is closed. No validations are accepted in any di-
rection. No passage is possible If a person enters the pedestrian
gate, the control unit interprets this as an unauthorised access at-
tempt.
Contr. D1/Closed
D2
Controlled direction 1 / Closed direction 2
The control unit only accepts validations in direction 1. Thus only
passages in direction 1 are possible.
In direction 2 the pedestrian gate is closed.
Closed D1/Contr.
D2
Closed D1/Controlled D2
In direction 1 the pedestrian gate is closed.
The control unit only accepts validations in direction 2. Thus only
passages in direction 2 are possible.
Contr. D1+D2 Controlled direction 1 and direction 2
The control unit accepts validations in both directions.
The validations are processed in the order in which they are re-
ceived. For example, if a validation is processed in direction 1, a
passage in direction 2 is not allowed.
Free D1/Closed
D2
Free direction 1 / Closed direction 2
No validation is required for passages in direction 1. All persons can
freely pass through the pedestrian gate in direction 1.
In direction 2 the pedestrian gate is closed.
