52
Control unit MGCplus
Description of menus and parameters
6.2.5.3 Warning light barriers (PE beams)
Operational view > Main menu > Settings > Safety > Warning light barriers (PE beams)
Parameter Description
Warning light barri-
ers (PE beams)
Set the maximum time that a light barrier (PE beam) may be occupied. If one
of the light barriers (PE beams) is occupied for longer than the set time, the
output "Warning light barriers (PE beam)" is set. ä Page 28, "Warning
light barriers (Output)".
Options (adjustment range)
› 0 s to 60 s
› 0 s: The output "Warning light barriers (PE beams)" is not set.
Factory setting
› 0 s
Table 28: Warning light barriers (PE beams)
6.2.6 Signalling
6.2.6.1 Buzzer
Operational view > Main menu > Settings > Signalling > Buzzer
Parameter Description
Buzzer Enable and disable events for which an acoustic signal is to be triggered.
Connect the acoustic signal either to the "Buzzer" or the "Buzzer (static)"
output. ä Page 27, "Buzzer (Output)" and ä Page 27, "Buzzer (static)".
An acoustic signal is possible for the following events:
› On error
› On validation
› On forced opening
› On fraud
› After passage
› On random hit
Options
› Inactive [ ]:
› Activated [ X ]
Factory setting
› Activated [ X ] for "On error", "On validation" and "On fraud"
Table 29: Buzzer
