59
Control unit MGCplus
Description of menus and parameters
6.3 Menu "Inputs/Outputs"
6.3.1 Digital inputs 1-8
ä Page 23, chapter 4.1.
6.3.2 Digital outputs 1-4 and relay outputs 1-6
ä Page 26, chapter 4.2.
6.4 Menu "Information"
6.4.1 Operating mode
Operational view > Main menu > Information > Operating mode
Parameter Description
Current mode Shows the current operating mode of the control unit.
Reason Shows the inputs and why this current operating mode is active.
Target mode
Table 34: Operating mode
6.4.2 People Counter
6.4.2.1 In direction 1
Operational view > Main menu > Information > People counter > In direction 1
Parameter Description
Passages total Shows the number of all validated and non-validated passages in direction 1.
Valid. passages Shows the number of all validated passages in direction 1.
Reverted Shows the number of people who have entered and exited the pedestrian
gate on one side.
Intrusion Shows the number of unauthorized access attempts of the "Intrusion" type
in direction 1.
Wrong direction Shows the number of unauthorized access attempts of the "Wrong direc-
tion" type in direction 2.
Tailgating Shows the number of unauthorized access attempts of the "Tailgating" type
in direction 1.
Table 35: People counter – In direction 1
