Magnetic MGCplus User Manual

19
Control unit MGCplus
Operation modes
3.4.2 Parameter "Control variant" – Option "Variant 1"
This chapter describes the control unit behaviour if the option "Variant 1" was
selected for the "Control variant" parameter.
"Variant 1" is using the "Control direction 1", "Control direction 2" and "Control
open mode" inputs. The open mode variants are selected with the "Control
open mode" input.
› Operating mode descriptions: ä Page 13, chapter 3.1.
› Open mode: ä Page 18, "OM (Open mode)".
› Parameter "Control variant": ä Page 41, "Control variant".
Input "Con-
trol direction
..."
Validation by
changing
from not set
to set at in-
put "Control
direction ..."
Permanent
signal at in-
put "Control
direction ..."
Resulting operating mode
Resulting control unit behaviour
1 2 1 2 1 2
Invalid
 
– – – –
This variant is available in the following cases:
› The pedestrian gate is controlled via API.
› An input with a specific operating mode is set.
The validations are performed via the inputs with
the functions "Validation direction 1" or "Valida-
tion direction 2".
Contr. D1+D2
     
Wait for a validation in direction 1 or direction 2.
     
Perform a passage in direction 1.
     
Perform a passage in direction 2.
     
Depending on the sequence of validations per-
formed, perform passages in direction 1 or in direc-
tion 2.
Free D1/Contr. D2
 
– –
 
Wait for a free passage in direction 1 or for an in-
coming validation in direction 2.
