Control unit MGCplus
Description of menus and parameters
6 Description of menus and parameters
6.1 Menu "Information"
Call and navigate
The operational view is displayed. ä Page 29, Fig. 2.
1. Press left button « ».
2. Use the left button « » to scroll within the menu.
3. The "Information" menu can be left as follows:
› Press the left button « » repeatedly until the operational view is dis-
played again or
› press the right button « ».
Operational view > Information
Parameter Description
Error, warning or
event messages
Display of the error, warning or event messages that occurred since the last
voltage reset, including date and time.
Use the « » and « » buttons to navigate through the messages.
If no messages are present, the menu is not displayed.
Inputs Displays the current settings for the digital inputs IN1 to IN8. Inputs with in-
verted functions are marked with a "|", e.g. "IN1: | Emergency open".
Outputs Displays the current settings for the digital outputs DO1 to DO4 and the relay
outputs NO1 to NO3 and NO/NC4 to NO/NC6. Outputs with inverted func-
tions are marked with a "|", e.g. "DO4: | GED1 green".
Light barriers (PE
beams)
Displays the occupation state of the light barriers (PE beams).
Table 17: Menu "Information"
