67
Control unit MGCplus
Corrective action
7.3.1 Event, warning and error messages – Logic control (Control unit)
"[nn]" is a placeholder for the number of the component that may be causing
an error.
Number Designation Possible cause Corrective action
ERROR
0x10001000
Hardware revision could
not be detected
MPM01 extension mod-
ule defective
› Contact service.
ERROR
0x11001000
SD card error MPM01 extension mod-
ule defective
› Contact service.
ERROR
0x20001000
CANopen system bus
could not be started
A defective IO extension
or motor control is con-
nected to the system
bus.
› Check the CAN bus wiring.
› Check the settings of the
terminating resistance.
ERROR
0x30013003
0x30023004
Motor for wing no. 1 / 2
not available
Incorrect motor address
setting or defective mo-
tor electronics
› Check for correct motor
address setting.
› Check the CAN bus wiring.
› Check the settings of the
terminating resistance.
› Contact service.
ERROR
0x3001F003
0x3002F004
Information on motor
no. 1 / 2 could not be
read
CAN system bus faulty › Check the CAN bus wiring.
› Check the settings of the
terminating resistance.
› Contact service.
ERROR
0x30011003
0x30021004
Internal referencing er-
ror on motor for wing
no. 1 / 2
Gear installed in motor
defective
› Change motor unit.
ERROR
0x3001F100
0x3002F100
Wrong motor type for
wing no. 1 / 2
Wrong motor type used › Change motor unit.
ERROR
0x4001F000
0x4002F000
The minimum required
span of wing 1 / 2 was
not reached during
homing
Wing 1 / 2 locked during
commissioning or wing
mechanics defective
› Remove obstacles that
block the movement of
the wing during commis-
sioning.
› Switch off the pedestrian
gate and check the wing
for ease of movement.
