57
Control unit MGCplus
Description of menus and parameters
Operational view > Main menu > Settings > Random check function
Parameter Description
Hit range The function depends on the selected mode.
For the "Counting" mode, use this parameter to set the value at which a hit
is to be generated.
For the "Random" mode, set the number range in which the random hits
must lie. For example, if you set the value to "100", the random hits must be
in the range 1 to 100.
IMPORTANT! The value for the "Count of hits" parameter can be a maximum
of 40 % of the value for the "Hit range" parameter. If the value set for the
"Count of hits" parameter is too high, the "Count of hits" parameter is auto-
matically adjusted.
Setting range
› 10 to 10000
Factory setting
› 1000
Count of hits Set the number of hits to be generated in the set Count of hits.
IMPORTANT! The value for the "Count of hits" parameter can be a maximum
of 40 % of the value for the "Hit range" parameter. If the value set for the
"Hit range" parameter is too high, the "Hit range" parameter is automatically
adjusted.
Setting range
› 1 to 1000
Factory setting
› 10
Delete validation Use the "Delete validation" parameter to specify whether the validation is to
be deleted automatically in the event of a random hit.
Options
› Yes (Activated [ X ])
Select this option if you want the check to take place before the passage.
The user leaves the area via a separate passage.
› No (Inactive [ ])
Select this option if you want the passage to take place when the hit is
confirmed. In this case, the check is carried out after the passage.
Factory setting
› No (Inactive [ ])
