37
4. Put the jack “A” Fig. 57 at the chassis
left side and start to lift, until liberaste
the tongue “B” and uncouple from trac-
tor.
5. Lower the jack, put the rear axle end
“A” Fig. 58 (inside the tunnel) and the
wheel “B”
6. Turn the hub “A” Fig. 59 to the position
II and mount the front wheel “B” (insi-
de the tongue). If it is necesary more
height, raise from the jack.
FIG.57
FIG.58
FIG.59
