1-23
1 - WHITE ARROW (REF: 833 553) 1-22
2 - BLACK ARROW (REF: 833 554) 1-22
3 - BASKET INSTRUCTIONS / LOAD CAPACITY
(REF: 833 551 & 525 14 665)
1-22
4A - SAFETY INSTRUCTIONS (REF: 685 608) 1-23
4B - TOWING (REF: 685 608) 1-23
4C - WASHING RECOMMENDATIONS (REF: 598 892) 1-23
5 - WHEEL LOAD
(REF: 833 552 & 525 23 351)
1-23
6 - LOCATION OF THE PLATFORM KEY (REF: 598 897) 1-24
7 - MANUAL CONTROL PROCEDURE
(REF: 833 547 & 833 548)
1-24
8 - EMERGENCY PUMP (REF: 833 549) 1-24
9 - RISK OF BEING CRUSHED (REF: 676 988) 1-25
10 - DANGER KEEP AWAY (REF: 679 450) 1-25
11 - DANGER RISK OF CRUSHING (REF: 679 452) 1-25
12 - RISK OF BURNS (REF: 683 112) 1-25
13 - SAFETY ATTACHMENTS (REF: 684 503) 1-26
14 - TIE-DOWN HOOK (REF: 833 041) 1-26
15 - HYDRAULIC OIL (REF: 597 652) 1-26
16 - DIESEL (REF: 683 437) 1-26
17 - ANTI-FREEZE (REF: 597 649) 1-27
18-A XY DRIVENABLE PENDULAR ARM (REF: 833 675) 1-27
18-B PENDULAR ARM ANGLE (REF: 833 523) 1-28
647382 EN (01/02/2015)
