2-41
45 - “DEAD MAN’S” PEDAL
- This pedal is fixed on the platform’s floor.
- This pedal must be pressed to perform movements from the basket console.
- When the pedal is released, no control can be used.
46 - BUZZER
- This buzzer is activated when the machine reaches the maximum authorized level of tilt or is
overloaded, and notifies the presence of certain faults.
- Intermittent buzzing: machine tilted.
- Continuous buzzing: machine overloaded.
- Various faults.
47 - SAFETY HARNESS ATTACHMENT POINTS
- These attachments must be used to fasten the harness when operators are in the basket.
48 - SAFETY RAIL
- You must hold the rail to climb into the basket so that the rail does not fall back as the operator
climbs in.
Do not hold the safety rail with a collar or string.
45
47
47
47
47
46
48
