Manitou 280 TJ - Abacus Sensors (Ref: 833 697 & 525 23 378); Endular Arm Block Coils

1-34
27 - LOWER ARM ANGLE SENSORS
This adhesive shows the location of angle sensors of the lower arm and the corresponding fault
codes.
28 - ABACUS SENSORS
This adhesive shows the location of Abacus sensors and the corresponding fault codes.
29 - PENDULAR ARM BLOCK COILS
This adhesive shows the location of the pendular arm block coils.
280 TJ
52523378
260 TJ
647382 EN (01/02/2015)
