Manitou 280 TJ - Page 39

1-35
30 - TURRET BLOCK COILS
This adhesive shows the location of the turret block coils.
31 - BRAKE BLOCK COILS
This adhesive shows the location of the brake block coils.
32 - POWER FUSES
This adhesive shows the location of the power fuses.
33 - POINT OF CENTRALIZED GREASING
This adhesive indicates the element which will profit from the greasing according to the selected
letter.
B
A
C
D
E
A
B
E
C
D
