2-36
29
26 - DIFFERENTIAL LOCKING CONTROL BUTTON
NB : This control must be used at the same time as translation.
Differential locking enables the two rear driven wheels to turn at the same speed.
- To utilise this, press this button 26; to stop using it, release the button and indicate stoppage
of translation.
Preferably use differential locking by keeping the wheels in the machine axis.
27 - BUZZER CONTROL BUTTON
- When this button 27 is pressed, the buzzer 17 sounds.
28 - FUEL LOW INDICATOR
- This indicator light comes on when the fuel level is low; the basket buzzer is activated:
• Level 1 alert: 3 beeps every 10 minutes,
• Level 2 alert: 3 beeps every minute,
• Level 3 alert: 3 beeps every 10 seconds and locking of the lifting movements after 5
seconds of activation.
29 - MACHINE FAULT LED
- This indicator light comes on and a short intermittent buzzer signal sounds when a major fault
occurs (see the SCREEN DISPLAY paragraph – page descriptions).
- Put the lifting platform out of service immediately.
- See the fault code display on the base screen.
- Types of major faults:
• Engine oil pressure
• Engine water temperature
• Overload sensor incoherence
• Pendular unit horizontality sensor incoherence
• Arm angle sensor incoherence.
27
26
28
