Manitou 280 TJ - Page 63

2-23
1 - KEY-OPERATED IGNITION SWITCH 2-26
2 - STARTER BUTTON 2-26
3 - GROUND OR PLATFORM CONTROL SELECTRO SWITCH 2-26
4 - EMERGENCY STOP 2-27
5 - ENGINE START-UP ASSISTANCE SELECTOR SWITCH 2-27
6 - INTERFACE SCREEN 2-28
7 - NAVIGATION KEY IN THE INTERFACE SCREEN 2-28
8 - DEAD MAN’S FUNCTION 2-29
9 - TURRET ROTATION KEYS 2-29
10 - RAISING AND LOWERING OF THE ARM 2-29
11 - EXTENSION AND RETRACTION OF THE TELESCOPE 2-30
12 - TELESCOPIC PENDULAR UNIT EXTENSION AND RETRACTION (EXCEPT 260 TJ) 2-30
13 - RAISING AND LOWERING OF THE PENDULAR UNIT 2-30
14 - TILTING OF THE BASKET DOWNWARDS AND UPWARDS 2-30
15 - BLOCKING TURRET ROTATION 2-31
16 - ROTATING FLASHING LIGHT 2-31
17 - TILT SENSOR 2-31
18 - BUZZER 2-31
19 - EMERGENCY PUMP BUTTON 2-32
20 - FUEL COCK 2-32
647382 EN (01/02/2015)
