Manitou 280 TJ - Page 90

2-50
E
Tilting the pendular
arm without basket
compensation
Rotating
the turret
right
Rotating
the turret
left
Retracting the
telescope
Extending the
telescope
Lowering the
lower arm and
telescope
Raising the
lower arm and
telescope
Lowering the
pendular arm
with basket
compensation
Raising the
pendular arm
with basket
compensation
Manually lowering the
lower arm – telescope
– basket compensation
assembly
F
Tilting the pendular
arm without basket
compensation
647382 EN (01/02/2015)
