RT880E SERVICE MANUAL LUBRICATION
unpainted fasteners and hardware, valves, slew ring
fasteners and all bare metal surfaces.
• Boom applications areas are; pivot pins, hose end and
fittings, jib pins and shafts, all bare metal surfaces,
headache ball pins/ hook block pins and fasteners.
• All hardware, clips, pins, hose connections not painted
will have treatment applied.
7650-13
Figure 9-14
2
3
4
5
6
7
8
1
8
12
10
9
14
13
15
16
1
11
1
17
18
19
