Manitowoc Grove YB5515

GROVE Published 10-21-2010, Control# 198-04 6-23
5540F/YB5515 SERVICE MANUAL ENGINE AND ENGINE SYSTEMS
6
FIGURE 6-21
p3033
LPG Shut-Off
Solenoid
LPG Mixer
Propane Vapor
Hose
Engine Vacuum
Line
LPG Vaporizer
Regulator
LPG Fuel System
FIGURE 6-22
p3035
LPG Fuel System
LPG Vaporizer
Regulator
Vacuum
Solenoid
Valve
Electronic Control
Unit (ECM)
LPG Vaporizer
Regulator
LPG Vaporizer
Regulator
Reference Only
