5540F/YB5515 SERVICE MANUAL
9-14 Published 10-21-2010, Control# 198-04
Item Description Qty Item Description Qty
1 Capscrew 4 18 O-ring 2
2 Lockwasher 4 19 Piston 1
3 Cover 1 20 Lining 1
4 Seal 1 21 Screw 2
5 Belleville Springs 1 22 Lining Assembly 1
6 Washer 1 23 Gasket 1
7 Adjusting Bolt 1 24 Bushing 1
8 Lock Nut 1 25 Lining 1
9 Piston 1 26 Housing 1
10 Back Ring 1 27 Screw 2
11 O-Ring 1 28 Seal 2
12 Push Rod 1 29 Grease Zerk 1
13 O-Ring 1 30 Bleeder Screw 1
14 Backup Ring 1 31 Mounting Bracket Assy 1
15 Piston 1 32 Nut 1
16 O-Ring 1 33 Bracket 1
17 Backup Ring 1 34 Pin 1
Reference Only
