ELECTRIC SYSTEM 5540F/YB5515 SERVICE MANUAL
3-14 Published 10-21-2010, Control# 198-04
Load Transmitter
Load Assembly
pin
Anti-Double
Block
Transmiiter
Receiver / Display
Angle / Lenght
Transmitter
Cable Reel
LMI System Arrangement
FIGURE 3-1
a1309
Reference Only
