Maple Armor FW106C - Ptu; Figure 5 AMI (Back); Figure 6 PTU

InstallationandOperationManual 
10



Figure5AMI(Back)
PTU
ThePTUcontainsaninternaltransformer,whichconverts110‐120VAC,or220‐240VACinputto24VACoutputto
PCU.



Figure6PTU


110‐120VACor220‐240VACinputisoptional.Aslideswitchisusedtofulfillthis
function.PleaserefertoPowerSupplyWiringsectionforswitchusageinformation.

110-120 VAC, 60Hz, 3.86A
Or 220-240 VAC 50Hz, 1.96A
24VAC
