Maple Armor FW106C - Alu

InstallationandOperationManual 
12

ALU 
 OneALUcansupportoneaddressableloopcircuit,whichsupportsupto252pointsofaddressabledevices.
 Initializesandoperatesalldevicesresidingontheloopandcommunicatesallrelevantdevicesandevent
information,suchasalarmsandtroubles,totheSystemCPU.
 Circuittopologysupport:Class
AorClassB.
 ALUaddressissetbytherotaryswitchontheboard.Thevalidaddressrangeis1~4.



Figure8ALU


TheALUmustbesettoacorrectaddressbeforeuse.PleaserefertoUnitAddress
Settingsectionfordetail.


Addressable Loop
Circuit
