ConfigurationandM aintenance
PCConfiguration
Programmingthepanelmaybedonebytemporarilyconnectingtheprogrammingporttoacomputer.Thisis
therecommendedmethodtoconfigurethepanel.
TheMapleArmorFW401ConfiguratorsoftwareisavailabletoconfigureofthecontrolpanelusingaPersonal
Computer(PC)withanEthernetport.Thisallowseaseof
operationbypreparingtheprograminadvanceand
downloadingittothecontrolpanelbyasimpleandfastoperation.
ControlPanelAccessControl
TheFW106/FW106Cprovidesconfigurationandmaintenancefunctionstosetandcontrolvariousfeaturesin
thesystem.
Theconfigurationandmaintenancefunctionsareprotectedbyaccesscontrol.Thefollowinglevelsofsecurity
protectthesystemfromunauthorizeduse:
 Level1–LockedDoor
 Level2–LockedDoorand4
‐digitPassword,Level2providescontrolfunctions.
 Level3–LockedDoorand4‐digitPassword,Level3providescontrolfunctionsandparameterchange
functions.
Toaccessthemaintenancefeatures,pressthe“MENU”buttonandselect“AccessToSystem”,enterthefour
digitcodewhenprompted,thenpress “OK”.

TheUserLevelisalsoaccessiblefromtheRemoteLCDAnnunciators.


