Maple Armor FW106C - Battery Installation

To Next Page

To Previous Page

InstallationandOperationManual 

21



BatteryInstallation

 Usethebatterycalculationcharttodeterminethebatterycapacityandsize.Placethebatteriesinthe

spaceprovidedinthebottomoftheenclosure.

 RefertoTable4 todeterminethemaximumavailablebatteryspace.



Table4BatterySpace

 mm inch

Length(for2batteries)

 410  16.14

Width

 168  6.61

Height

 200  7.87



Figure15BatteryInstallation





Battery

position
