Maple Armor FW106C - External Network Circuit Wiring

InstallationandOperationManual 
33

ExternalNetworkCircuitWiring
Externalnetworkcircuitcanaddressupto110panelsand/orremoteannunciators.
FW106/FW106Ccontrolpanelcanconnecttopanels/annunciatorsbyusingExternalNetworkUnit.

RemoteDevicePower–Thecontrolpanelauxiliarypowercanprovidepowerfor4annunciators.Eachaddress
onthecircuitmustbefullypoweredfromeitherauxiliary
powerofcontrolpanelUL/ULCListedpowersupply
foruseinfirealarmsystems.
Whenconnectingpanels/annunciatorsontheexternalnetworkcircuit,thedatawiresmustbedaisychained
andwithnoT‐tapstopreservetheintegrityofthedata.Thefollowingdiagramsshowtheproperwiring.
ExternalNetworkCircuitWiring‐ClassB
Figure27ExternalNetworkCircuitWiring‐ClassB
AbouttheXNUJumper
EachXNUhasaninternaljumperonitsupperrightsidewhichmustfirstbecorrectlyconfigured.

If this XNU is located at the end of the external network circuit, the jumper
mustbeswitchedto“ON”.










