InstallationandOperationManual 
16

INSTALLATION
Cautions
1. RemovethePCBforanyprocedurethatmaycausedust,metalshavings,grea se,orsuchmattertoaffectthe
operationoftheboardsorgetincontactwiththeunits.
2. Disconnectallsourcesofpowerprior toinstallingorremovingmodules,connectingordisconnectingwiring
andprogrammingjumpers.
3.
Grouptheincomingwiresthroughthetopoftheenclosure.Foreasyidentification andneatnessuseawire
tie.
4. DONOTinsertcablesthroughbottomofthebox.ThisspaceisreservedforBatteries.
ControlPanelLocation
Thecontrolpanelshouldbelocatednearanexitatgroundlevelwherethenormalambienttemperatureis
maintainedwithinthecontrolpanelspecification(seetheSpecificationsandFeaturessection).Theunitshould
beinanareafreeofdust,vibration,moisture,andcondensation.Anyauxiliarybatteryboxorotheraccessory

notconnectedthroughaprotectivedeviceoracircuitdesignedforremoteconnectionmustbewithin20ft.and
inthesameroom,connectedthroughtheelectricalconduit.
ControlPanelInstallationNotice
Thecabinetmustbefastenedsecurelytoaclean,dry,shock‐free,andvibration‐freesurfaceinaprotected
environment.Considerthefollowingwhenmountingthecabinet:
 MountingheightforvisualandmanualaccesstotheDisplayBoard
 Weightandsizeofcabinet
 Localmountingcodes

When
mountingthecabinet,positionthecabinetclearofobstructionssothatthedoorcanopenfreelyand
indicatorsandcontrolsareeasilyaccessible.
Thefirealarmcontrolpanelmustbemountedinaproperlyaccessiblelocation,asrequiredbytheapplicable
codesandtheAHJ.
Installationmustbedonebyqualified
personnelwhohavethoroughlyreadandwhounderstandsthese
instructions.

