UnitAddressSetting
Units(ALU,NOU,ROU,PCU)haveaninternalrotaryswitchtosetanaddress.Therotaryswitchislocatedatthe
bottomofeachunit’scover.

Figure16UnitAddressSwitch

XNU’saddressshouldbeprogrammedonthepanel’sattributescreen(RefertoProgrammingManual
DOC‐FW106‐PMfordetails)

Theunitmustbesettoanappropriateaddressbeforeuse. ThevalidaddressrangeislistedinTable5.

Table5UnitAddressRange
UnitType AddressRange
ALU
1~4
NOU
1~5
ROU
1
PCU
1
XNU
1~110







