Check operation of IC151(ADV8003).
(32) Check Control signal (I2C).
IswaveformconrmedinTP[[IP_SCL/IP_SDA],whenthepoweristurnedon?
(If the waveform is not the reference waveform, proceed to NO.)
Q1502 and surrounding circuitry are
defective.
NO
YES
YES
YES
YES
YES
(30) Check xtal oscillator.
Is oscillation of X1501(27MHz) transmitted?
(27) Check xtal oscillator.
Is oscillation of X1201(27MHz) transmitted?
(31) Check RESET.
IsRESETwaveformconrmedinTP[8003_RESET],whenpower
is turned on? (If not reference waveform, proceed to "NO".)
(28) Check RESET.
IsRESETwaveformconrmedinTP[7850_RESET],whenpower
is turned on? (If not reference waveform, proceed to "NO".)
The pattern and circuit from the HDMI connector (JK151/JK152) to
the IC(IC151) is defective, or HDMI output circuitry is defective.
(29) Check power supply.
Are 1.8V supplied to L1501-L1505/C1563/C1570/L1512/L1521/
L1522?
Are 3.3V supplied to L1508/L1510/L1514?
The power supply circuitry is defective.
The X1501 or IC151 is defective.
The X1201 or IC121 is defective.
The RESET circuitry or IC151 is defective.
The RESET circuitry or IC121 is defective.
