99
YES
NO
YES
(18)
When using a
marantz BD/DVD
player, is the FL
display's "HDMI"
indicator lit?
If using a non-
marantz BD/DVD
player, proceed
to "NO".
The BD/DVD player does not recognize the connection with the
set.
(19)
Is the "H"(3V-5V) signal outputted of HDMI connector (JK101/JK501-
JK506 : TP[HPD])?
With the BD/DVD player connected, Check voltage of the HDMI
connector for the input on the side on which the BD/DVD player is
connected.IscommunicationwaveformconrmedinTP[DDC_CLK]/
TP[DDC_DATA] around each HDMI connector ?
Is TMDS line of HDMI connector terminated by the TMDS signal of 3.3V
and is the signal output?
The pattern and
circuit from the
HDMI connector
( JK101/JK501-
JK506 ) to the IC
(IC101/121/501)
are defective.
NO NO
(20)
VIDEO CONVERT : Is the picture output when it is set to off?
(After item (21) : To be "VIDEO CONVERT:OFF" setting.)
IC151(ADV8003) and surrounding circuitry
are defective.
YES
YES
YES
YES
Check operation of each device.
(AMP source : BD[i/p:Analog&HDMI,MONITOR OUT:Auto] / Video input of player :
480P / Connect the TV. / ZONE2 : ON)
Check operation of IC501(SiI9575).
(21) Check power supply.
Are 5V or 3.3V or 1.3V supplied to IC501 (each power supply pin)?
Refer to [Detail C] of the substrate for test point.
(23) Check RESET.
IsRESETwaveformconrmedinTP[SiI9575_RESET],whenthepoweris
turned on?(If the waveform is not the reference waveform, proceed to NO.)
(25) Check output signal.
IsTMDSwaveformconrmedin142-149pin/152-159pin.Iscommunication
waveformofDDC_SCL/DDC_SDAconrmedin106,107pin/109,110pin?(Ifthe
waveform is not the reference waveform, proceed to NO.)
(24) Check Control signal (I2C).
IswaveformconrmedinTP[HDMI_SCL/HDMI_SDA],whenthepoweris
turned on? (If the waveform is not the reference waveform, proceed to NO.)
The power supply circuitry is defective.
The RESET circuitry or IC501 is defective.
The IC501 is defective.
The pattern is defective of the HDMI_SCL/
HDMI_SDA line.
NO
YES
NO
NO
NO
The HDMI input circuitry is defective.
(IC121 or IC501 and surrounding circuitry)
Check operation of IC121 (ADV7850).
(26) Check power supply.
Are 1.8V supplied to L1203/L1204/C1393/L1208/L1211?
Are 3.3V supplied to L1206/L1207/L1212/L1213?
The power supply circuitry is defective.
NO
YES
NO
YES
(22) Check xtal oscillator.
Is oscillation of X5001(27MHz) transmitted?
The X5001 or IC501 is defective.
