Marantz AV7701 - Page 103

103
DDC_CLK/DDC_DATA/TMDS : Check items HDMI to HDMI (17)/(19)/(25)/(33)/(34)
Timing waveform illustration from the start of CEC3.3V to when reset is released : Check items (23)
0.9V
2.48V
CEC3.3V
338ms
Sil9575_RESET
DDC_CLK
DDC_DATA
