104
Controlled waveform (I2C), when power is turned on : Check items (24)/(32)
Timing waveform illustration from the start of CEC3.3V to when reset is released : Check items (31)
Timing waveform illustration from the start of CEC3.3V to when reset is released : Check items (28)
CEC3.3V
338ms
7850_RESET
314ms
DV3.3V
Zoom
8003_RESET
10ms 10ms
SCL
Zoom
SDA
Power ON
