Conrmation item Setting and display
Details of how to operate remote controller
*a)
Output sequence of remote control codes
※
It is useful to form a macro program. *b)
Contents of conrmation Remarks
9
HDMI (signal) Path
(ZONE2)
Video Convert(IP Scaler) : OFF, All Sources
All ZONE:ON
Main Display:
V D V D
0 1
Sub Display:
V 0 1
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : HDMI (ZONE2 Function) / Output : HDMI (ZONE2)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [1/AUTO]
e
KEY1/AUTO (Main Zone)
(Initialization & Video Convert All OFF)
8.Press [Z2]
9.Press [POWER ON]
r
ZONE2 POWER ON
10.Press [DVD] twice
t
DVD (Main Zone)
11.Press [AMP]
12.Press [Z2]
y
Select remote control "ZONE2"
13.Press [DVD] twice
u
DVD (Zone2)
5.5. Audio system conrmation items
g.XX:Refertotheblockdiagramoftheg.XXth.
Conrmation item Setting and display Details of how to operate remote controller
Output sequence of remote control codes
※
It is useful to form a macro program.
Contents of conrmation Remarks
1
Analog (signal) Path Input Mode : Fixed ANALOG
SURROUND mode : DIRECT
Amp assign : NORMAL
Main Display:
A D V D
0 1
Sub Display:
A 0 1
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : Analog / Output : Pre OUT(Front L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [7/T.TONE]
e
KEY7/T.TONE (Main Zone)
(Initialization & Amp assign NORMAL&
Input Mode Fixed ANALOG &
SURROUND mode DIRECT)
8.Press [DVD] twice
r
DVD (Main Zone)
2
DIGITAL (signal) Path
(MAIN)
Input Mode : Fixed DIGITAL
Amp assign : NORMAL
Main Display:
A D V D
0 2
Sub Display:
A 0 2
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : Digital / Output : Pre OUT(Front L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [8/CH LVL]
e
KEY8/CH LVL (Main Zone)
(Initialization & Amp assign NORMAL&
Input Mode Fixed DIGITAL)
8.Press [DVD] twice
r
DVD (Main Zone)
3
HDMI (signal) Path Input Mode : Fixed HDMI
Amp assign : NORMAL
Main Display:
A D V D
0 5
Sub Display:
A 0 5
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : HDMI / Output : Pre OUT(Front L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [SURROUND]
e
SURROUND
(Initialization & Amp assign NORMAL
& Input Mode Fixed HDMI)
8.Press [DVD] twice
r
DVD (Main Zone)
4
A/D (signal) Path
(Main Zone)
Amp assign : NORMAL
SURROUND mode : Multi ch STEREO
Vol -20dB
SpeakerCong:SSSSY
(Front/Center/Surround/SourroundBack : Small, SW : Yes)
Main Display:
A D V D
0 6
Sub Display:
A 0 6
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : Analog / Output : Pre OUT(Front L/R), SW(20Hz)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [PURE DIRECT]
e
PURE DIRECT
(Initialization & Amp assign NORMAL &
SURROUND mode : Multi ch STEREO
& ZONE2 Volume -20dB)
8.Press [DVD] twice
r
DVD (Main Zone)
g.9
g.10
g.11
g.12
g.13
