Conrmation item Setting and display Details of how to operate remote controller
Output sequence of remote control codes
※
It is useful to form a macro program.
Contents of conrmation Remarks
5
Amp Assign (signal) Path
(Amp Assign : ZONE2)
Amp assign : ZONE2
ZONE2 Function : Source
Zone2 Vol -20dB
Main Display:
A D V D
0 7
Sub Display:
A 0 7
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : Analog / Output : Pre OUT (ZONE2 L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [P2]
e
P2
(Initialization & Amp assign ZONE2 &
SURROUND mode : Multi ch STEREO
& ZONE2 Volume -20dB)
8.Press [Z2]
9.Press [POWER ON]
r
ZONE2 POWER ON
10.Press [AMP]
11.Press [DVD] twice
t
DVD (Main Zone)
6
Amp Assign (signal) Path
(Amp Assign : ZONE3)
Amp assign : ZONE3
SURROUND mode : Multi ch STEREO
Zone3 Vol -20dB
Main Display:
A D V D
0 8
Sub Display:
A 0 8
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : Analog / Output : Pre OUT (ZONE3 L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [P3]
e
P3
(Initialization & Amp assign ZONE3 &
SURROUND mode : Multi ch STEREO
& ZONE3 Volume -20dB)
8.Press [Z3]
9.Press [POWER ON]
r
ZONE3 POWER ON
10.Press [AMP]
11.Press [DVD] twice
t
DVD (Main Zone)
8
Front Height (signal) Path Amp assign : Front Height
SURROUND mode : Multi ch STEREO
Vol -20dB
Surround Parameter-Speaker : F.Height
Main Display:
A D V D
0 1 4
Sub Display:
A 0 1 4
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : Analog / Output : (F.HEIGHT L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [+10/SLEEP]
e
+10/SLEEP (Main Zone)
(Initialization & Amp assign NORMAL
& SURROUND mode : Multi ch
STEREO & Volume -20dB & Surround
Parameter Speaker F.HEIGHT)
8.Press [DVD] twice
r
DVD (Main Zone)
10
Front Wide (signal) Path Amp assign : NORMAL
SURROUND mode : Multi ch STEREO
Vol -20dB
Surround Parameter-Speaker : F.Wide
Main Display:
A D V D
0 1 5
Sub Display:
A 0 1 5
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : Analog / Output : (F.WIDE L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [SEARCH/INFO]
e
SEARCH/INFO
(Initialization & Amp assign NORMAL
& SURROUND mode : Multi ch
STEREO & Volume -20dB & Surround
Parameter Speaker F.WIDE)
8. Press [DVD] twice
r
DVD (Main Zone)
