Martin Tornado - Safety Features Installation

© Martin Engineering GmbH 22 M3727UK-09/15
Installation
5.2.3 Installing the manual safety slide
1. Screw the blow-off flange of the safety slide to the silo flange.
2. Screw the air cannon's blow-off flange to the flange of the
safety slide.
3. Check all of the screw connections for tight fit and retighten
them as needed, see Tab.2.
5.2.4 Installing the Martin
®
Blast Guard
Follow the instructions in the MARTIN
®
Blast Guard operating
manual for this.
5.2.5 Connecting the air cannon to the flange bracket
CAUTION! RISK OF INJURY!
The locking plate of the safety slider can project from the
installation area under certain installation conditions and pose
arisk.
Use appropriate signs and/or labels to draw attention to the hazard
point.
NOTE
Either the Martin
®
Blast Guard or the manual safety slide can be
installed.
CAUTION! RISK OF INJURY!
Contamination of the valve can cause the air cannon to
malfunction. Blow-off air can cause personal injury.
Align the pipe elbow on the valve vent opening downwards if
possible and turn it away from walkways.
The vent opening must not be closed and its diameter not
reduced.
