Part numbers
9.5 MARTIN
®
TORNADO 6-inch air cannon
Fig. 20: Part No. 37853-XXXXXX-XXXX+E
*BSP = British Standard Piping
438
Füllanschluß
Fill port G3/8" BSP
Control port G3/8" BSP /
Steueranschluß
TD = Tank diameter /
Behälterdurchmesser
1
2
5
4
8
9
3
7
10
6
Gesamthöhe
G6"
OH = Overall height /
634
